Export-Boy 204

Export-Boy 204; Grundig Radio- (ID = 81332) Radio

Export-Boy 204; Grundig Radio- (ID = 81334) Radio

Export-Boy 204; Grundig Radio- (ID = 81336) Radio

Export-Boy 204; Grundig Radio- (ID = 81338) Radio
Export-Boy 204; Grundig Radio- (ID = 449866) Radio
Use red slider bar for more.
Export-Boy 204; Grundig Radio- (ID = 449866) Radio
Grundig Radio-: Export-Boy 204 [Radio] ID = 449866 465x351
Select picture or schematic to display from thumbnails on the right and click for download.
For model Export-Boy 204, Grundig (Radio-Vertrieb, RVF, Radiowerke)

Country:  Germany
Manufacturer / Brand:  Grundig (Radio-Vertrieb, RVF, Radiowerke)
alternative name

Grundig Portugal || Grundig USA / Lextronix
Year: 1964/1965 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 9: AF121 AF125 OC70 AF127 AF127 AC126 AC125 AC128 AC128
Main principle Superheterodyne (common); ZF/IF 460 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast plus more than 2 Short Wave bands.
Details
Power type and voltage Dry Batteries / 6 × 1,5; 9 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 1 W (unknown quality)
from Radiomuseum.org Model: Export-Boy 204 - Grundig Radio-Vertrieb, RVF,
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 260 x 160 x 70 mm / 10.2 x 6.3 x 2.8 inch
Notes Netzbetrieb mit nachträglich einsetzbarem Netzteil TN9 (52,- DM) möglich.
Net weight (2.2 lb = 1 kg) 1.9 kg / 4 lb 3 oz (4.185 lb)
Price in first year of sale 300.00 DM
Source of data Handbuch VDRG 1964/1965 / Radiokatalog Band 1, Ernst Erb
