Fernauge FA 73

Fernauge FA 73; Grundig Radio- (ID = 2073544) TV-studio

Fernauge FA 73; Grundig Radio- (ID = 2073545) TV-studio

Fernauge FA 73; Grundig Radio- (ID = 2073546) TV-studio

Fernauge FA 73; Grundig Radio- (ID = 2073555) TV-studio

Fernauge FA 73; Grundig Radio- (ID = 2073557) TV-studio

Fernauge FA 73; Grundig Radio- (ID = 2073558) TV-studio

Fernauge FA 73; Grundig Radio- (ID = 2073560) TV-studio

Fernauge FA 73; Grundig Radio- (ID = 2073561) TV-studio

Fernauge FA 73; Grundig Radio- (ID = 2073563) TV-studio
Fernauge FA 73; Grundig Radio- (ID = 1989071) TV-studio Fernauge FA 73; Grundig Radio- (ID = 1989070) TV-studio
Fernauge FA 73; Grundig Radio- (ID = 2175586) TV-studio Fernauge FA 73; Grundig Radio- (ID = 2175587) TV-studio
Use red slider bar for more.
Fernauge FA 73; Grundig Radio- (ID = 1989071) TV-studio
Grundig Radio-: Fernauge FA 73 [TV-studio] ID = 1989071 1384x635
Select picture or schematic to display from thumbnails on the right and click for download.
For model Fernauge FA 73, Grundig (Radio-Vertrieb, RVF, Radiowerke):
Aus Grundig TI 3/76

Country:  Germany
Manufacturer / Brand:  Grundig (Radio-Vertrieb, RVF, Radiowerke)
alternative name

Grundig Portugal || Grundig USA / Lextronix
Year: 1976 Category: Television-Camera (Broadcast, professional) and studio engineering
Valves / Tubes 1:
Semiconductors (the count is only for transistors) Semiconductors present.
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 110, 117, 220, 240 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Fernauge FA 73 - Grundig Radio-Vertrieb, RVF,
Material Metal case
Dimensions (WHD) 127 x 120 x 405 mm / 5 x 4.7 x 15.9 inch
Notes

S/W Kamera, extern synchronisierbar, TV Norm 625 Zeilen 50 Hz, Auflösung bis 12 MHz.

Bildaufnahmeröhre: 2/3" Vidikon (Si-Dioden-Vidikon, Plumbikon und Newvicon möglich)
Objektivanschluss: C-Mount Gewinde

Gewichtsangabe ohne Objektiv.

Net weight (2.2 lb = 1 kg) 4.1 kg / 9 lb 0.5 oz (9.031 lb)
Mentioned in -- Original-techn. papers.

Model page created by Holger Ortmann. See "Data change" for further contributors.
