Frequenzmesser (Frequency-Meter) FM1

Frequenzmesser FM1; Grundig Radio- (ID = 1796221) Equipment

Frequenzmesser FM1; Grundig Radio- (ID = 2040286) Equipment
Frequenzmesser FM1; Grundig Radio- (ID = 1796220) Equipment Frequenzmesser FM1; Grundig Radio- (ID = 2040289) Equipment
Use red slider bar for more.
Frequenzmesser FM1; Grundig Radio- (ID = 1796220) Equipment
Grundig Radio-: Frequenzmesser FM1 [Equipment] ID = 1796220 741x1213
Select picture or schematic to display from thumbnails on the right and click for download.
For model Frequenzmesser (Frequency-Meter) FM1, Grundig (Radio-Vertrieb, RVF, Radiowerke)

Country:  Germany
Manufacturer / Brand:  Grundig (Radio-Vertrieb, RVF, Radiowerke)
alternative name

Grundig Portugal || Grundig USA / Lextronix
Year: 1967 Category: Service- or Lab Equipment
Wave bands - without
Details
Power type and voltage No Power needed
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Frequenzmesser FM1 - Grundig Radio-Vertrieb, RVF,
Material Various materials
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Notes

Grundig Frequenzmesser FM1, zur Bestimmung der Frequenz von Lösch- und Vormagnetisierungsgeneratoren von Tonbandgeräten.

Messbereiche: 18-50 und 50-120 kHz.

Mentioned in -- Original-techn. papers.
Literature/Schematics (1) Österreichische Radioschau, Heft 4, 1967, Seite 203

Model page created by Heiko zur Mühlen. See "Data change" for further contributors.
