K-PR 15

K-PR 15; Grundig Radio- (ID = 339447) Radio K-PR 15; Grundig Radio- (ID = 339448) Radio
K-PR 15; Grundig Radio- (ID = 339451) Radio K-PR 15; Grundig Radio- (ID = 2323734) Radio
K-PR 15; Grundig Radio- (ID = 2323735) Radio K-PR 15; Grundig Radio- (ID = 2323736) Radio
K-PR 15; Grundig Radio- (ID = 2323737) Radio K-PR 15; Grundig Radio- (ID = 2323738) Radio
K-PR 15; Grundig Radio- (ID = 2323739) Radio K-PR 15; Grundig Radio- (ID = 2323740) Radio
Use red slider bar for more.
K-PR 15; Grundig Radio- (ID = 339447) Radio
Grundig Radio-: K-PR 15 [Radio] ID = 339447 511x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model K-PR 15, Grundig (Radio-Vertrieb, RVF, Radiowerke)

Country:  Germany
Manufacturer / Brand:  Grundig (Radio-Vertrieb, RVF, Radiowerke)
alternative name

Grundig Portugal || Grundig USA / Lextronix
Year: 1985 ?? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Superheterodyne (common)
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Dry Batteries / 2 × 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5.7 cm = 2.2 inch
Power out 0.25 W (unknown quality)
from Radiomuseum.org Model: K-PR 15 - Grundig Radio-Vertrieb, RVF,
Material Modern plastics (no Bakelite or Catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 130 x 75 x 32 mm / 5.1 x 3 x 1.3 inch
Net weight (2.2 lb = 1 kg) 0.2 kg / 0 lb 7 oz (0.441 lb)
Source of data - - Data from my own collection

Model page created by Josef Loidl. See "Data change" for further contributors.
