Reise Super, Der kleine Boy, Kleiner Boy

Reise Super, Der kleine Boy, Kleiner Boy ; Grundig Radio- (ID = 284311) Radio
Reise Super, Der kleine Boy, Kleiner Boy ; Grundig Radio- (ID = 22485) Radio Reise Super, Der kleine Boy, Kleiner Boy ; Grundig Radio- (ID = 580545) Radio
Reise Super, Der kleine Boy, Kleiner Boy ; Grundig Radio- (ID = 175979) Radio Reise Super, Der kleine Boy, Kleiner Boy ; Grundig Radio- (ID = 914586) Radio
Reise Super, Der kleine Boy, Kleiner Boy ; Grundig Radio- (ID = 914585) Radio Reise Super, Der kleine Boy, Kleiner Boy ; Grundig Radio- (ID = 175978) Radio
Reise Super, Der kleine Boy, Kleiner Boy ; Grundig Radio- (ID = 363246) Radio Reise Super, Der kleine Boy, Kleiner Boy ; Grundig Radio- (ID = 515463) Radio
Reise Super, Der kleine Boy, Kleiner Boy ; Grundig Radio- (ID = 580539) Radio Reise Super, Der kleine Boy, Kleiner Boy ; Grundig Radio- (ID = 580540) Radio
Use red slider bar for more.
Reise Super, Der kleine Boy, Kleiner Boy ; Grundig Radio- (ID = 22485) Radio
Grundig Radio-: Reise Super, Der kleine Boy, Kleiner Boy [Radio] ID = 22485 781x518
Select picture or schematic to display from thumbnails on the right and click for download.
For model Reise Super, Der kleine Boy, Kleiner Boy, Grundig (Radio-Vertrieb, RVF, Radiowerke)

Country:  Germany
Manufacturer / Brand:  Grundig (Radio-Vertrieb, RVF, Radiowerke)
alternative name

Grundig Portugal || Grundig USA / Lextronix
Year: 1951/1952 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: DK91 or 1R5 DF91 or 1T4 DAF91 or 1S5 DL92 or 3S4
Semiconductors (the count is only for transistors) 220E60
Main principle Super-Heterodyne (Super in general); ZF/IF 468 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Line / Batteries (any type) / AC/DC 220 / 9 & 90 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Reise Super, Der kleine Boy, Kleiner Boy - Grundig Radio-Vertrieb, RVF,
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 269 x 218 x 115 mm / 10.6 x 8.6 x 4.5 inch
Notes

Eingebaute Rahmenantenne, Polystyrol-Gehäuse in rot.

Net weight (2.2 lb = 1 kg) 3 kg / 6 lb 9.7 oz (6.608 lb)
Price in first year of sale 186.00 DM
Collectors' prices
Source of data Kat.d.Rundf.GrossH.1951/52 / Radiokatalog Band 1, Ernst Erb
Mentioned in Funkschau (5103)
Picture reference Das Gerät ist im Doppelband "Historische Radios" von Günther Abele abgebildet.
