Klirranalysator KM6

Klirranalysator KM6; Grundig Radio- (ID = 401830) Equipment

Klirranalysator KM6; Grundig Radio- (ID = 401831) Equipment

Klirranalysator KM6; Grundig Radio- (ID = 401832) Equipment

Klirranalysator KM6; Grundig Radio- (ID = 401833) Equipment

Klirranalysator KM6; Grundig Radio- (ID = 1170625) Equipment

Klirranalysator KM6; Grundig Radio- (ID = 1170626) Equipment

Klirranalysator KM6; Grundig Radio- (ID = 1170627) Equipment

Klirranalysator KM6; Grundig Radio- (ID = 1170628) Equipment

Klirranalysator KM6; Grundig Radio- (ID = 1170629) Equipment

Klirranalysator KM6; Grundig Radio- (ID = 1170630) Equipment
Klirranalysator KM6; Grundig Radio- (ID = 1170620) Equipment Klirranalysator KM6; Grundig Radio- (ID = 1170622) Equipment
Klirranalysator KM6; Grundig Radio- (ID = 1170623) Equipment Klirranalysator KM6; Grundig Radio- (ID = 214385) Equipment
Klirranalysator KM6; Grundig Radio- (ID = 459216) Equipment Klirranalysator KM6; Grundig Radio- (ID = 1004047) Equipment
Klirranalysator KM6; Grundig Radio- (ID = 1170624) Equipment Klirranalysator KM6; Grundig Radio- (ID = 2511490) Equipment
Klirranalysator KM6; Grundig Radio- (ID = 2511491) Equipment Klirranalysator KM6; Grundig Radio- (ID = 2511492) Equipment
Use red slider bar for more.
Klirranalysator KM6; Grundig Radio- (ID = 1170620) Equipment
Grundig Radio-: Klirranalysator KM6 [Equipment] ID = 1170620 900x522
Select picture or schematic to display from thumbnails on the right and click for download.
For model Klirranalysator KM6, Grundig (Radio-Vertrieb, RVF, Radiowerke)

Country:  Germany
Manufacturer / Brand:  Grundig (Radio-Vertrieb, RVF, Radiowerke)
alternative name

Grundig Portugal || Grundig USA / Lextronix
Year: 1975–1982 ? Category: Service- or Lab Equipment
Semiconductors (the count is only for transistors) 91:
Main principle Audio-Amplification
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 110/220 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Klirranalysator KM6 - Grundig Radio-Vertrieb, RVF,
Material Metal case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 365 x 155 x 275 mm / 14.4 x 6.1 x 10.8 inch
Notes 8 Integrierte Schaltkreise; Klirranalysator für 10 Hz - 1 MHz, Voltmeter von 1 mV - 300 V, kges mit Vollausschlag 0,1 - 100 % jeweils in 6 Meßbereichen. 3 spezielle Fotokoppler, 2 davon mit Glühlämpchen (in Gehäuse verschweißt), ohne die Fotokoppler ist keine Klirrfaktor messung bzw. nur eingeschränkt manuell möglich.
Net weight (2.2 lb = 1 kg) 5 kg / 11 lb 0.2 oz (11.013 lb)
Mentioned in (A) Radio Elektronik Schau; Heft 11, 1975 Werbeschaltung
Literature/Schematics (1) -- Original-techn. papers. (Grundig Technische Informationen 3-1974)

Model page created by a member from A. See "Data change" for further contributors.
