Grundig Radio-: KS717 Ch= CS160RF [Radio] ID = 256694 486x416
Select picture or schematic to display from thumbnails on the right and click for download.
For model KS717 Ch= CS160RF, Grundig (Radio-Vertrieb, RVF, Radiowerke):
ks717 chassis cs160

Country:  Germany
Manufacturer / Brand:  Grundig (Radio-Vertrieb, RVF, Radiowerke)
alternative name

Grundig Portugal || Grundig USA / Lextronix
Year: 1969–1972 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 21: BF222 or. BF314 BF185 or. BF255 BF195 BF194 BF238 BF237 BC149 or. BC239 BC149 or. BC239 BC181 BC181 AC187 AC188 AC187 AC188 AD162
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz
Tuned circuits 7 AM circuit(s)     11 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details Changer (Record changer)
Power type and voltage Alternating Current supply (AC) / 110; 220 Volt
Loudspeaker 2 Loudspeakers
Power out 8 W (unknown quality)
from Radiomuseum.org Model: KS717 Ch= CS160RF - Grundig Radio-Vertrieb, RVF,
Material Wooden case
Shape Console with Push Buttons.
Dimensions (WHD) 880 x 830 x 370 mm / 34.6 x 32.7 x 14.6 inch
Notes Der Empfänger KS717 basiert auf dem Chassis CS160RF. Der Stereodecoder 10 ist eingebaut, die Ausgangsleistung beträgt 2 x 4 Watt. Das Phonochassis ist ein Automatic 36 mit einem keramischen Abtastsystem, Typ 22GP200. Es gibt die Gehäuseausführungen mitteldunkel hochglanzpoliert oder hell mattiert.
Net weight (2.2 lb = 1 kg) 36 kg / 79 lb 4.7 oz (79.295 lb)
External source of data erb
Source of data Handbuch VDRG 1969/1970
Mentioned in Handbuch VDRG 1970/1971
Literature/Schematics (1) -- Original-techn. papers.
