For model MC10, Grundig (Radio-Vertrieb, RVF, Radiowerke):
Bild aus Grundig Service Unterlagen

Country:  Germany
Manufacturer / Brand:  Grundig (Radio-Vertrieb, RVF, Radiowerke)
alternative name

Grundig Portugal || Grundig USA / Lextronix
Year: 1993 ? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Superheterodyne (common)
Wave bands Broadcast, Long Wave and FM or UHF.
Details Other Combination - see Notes; Radio Control (+Remote Wire etc)
Power type and voltage Alternating Current supply (AC) / 230 Volt
Loudspeaker - This model requires external speaker(s).
Power out
from Radiomuseum.org Model: MC10 - Grundig Radio-Vertrieb, RVF,
Material Various materials
Shape Book-shelf unit.
Notes MC10 mit Doppel-Deck und CD Player Verstärker 2x 35 Watt Musikleistung an 6 Ohm, Frequenzgang von 20 Hz bis 20000 Hz.
Mentioned in Original Grundig Service Unterlagen

Model page created by Josef Pilz. See "Data change" for further contributors.
