Merano 3 Ch= CS160MS

Merano 3 Ch= CS160MS; Grundig Radio- (ID = 644049) Radio

Merano 3 Ch= CS160MS; Grundig Radio- (ID = 644052) Radio

Merano 3 Ch= CS160MS; Grundig Radio- (ID = 644053) Radio

Merano 3 Ch= CS160MS; Grundig Radio- (ID = 644054) Radio

Merano 3 Ch= CS160MS; Grundig Radio- (ID = 644056) Radio

Merano 3 Ch= CS160MS; Grundig Radio- (ID = 644058) Radio

Merano 3 Ch= CS160MS; Grundig Radio- (ID = 644059) Radio

Merano 3 Ch= CS160MS; Grundig Radio- (ID = 644060) Radio

Merano 3 Ch= CS160MS; Grundig Radio- (ID = 644061) Radio
Merano 3 Ch= CS160MS; Grundig Radio- (ID = 38887) Radio Merano 3 Ch= CS160MS; Grundig Radio- (ID = 1546769) Radio
Use red slider bar for more.
Merano 3 Ch= CS160MS; Grundig Radio- (ID = 38887) Radio
Grundig Radio-: Merano 3 Ch= CS160MS [Radio] ID = 38887 933x386
Select picture or schematic to display from thumbnails on the right and click for download.
For model Merano 3 Ch= CS160MS, Grundig (Radio-Vertrieb, RVF, Radiowerke)

Country:  Germany
Manufacturer / Brand:  Grundig (Radio-Vertrieb, RVF, Radiowerke)
alternative name

Grundig Portugal || Grundig USA / Lextronix
Year: 1970–1972 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 21: BF222 or. BF314 BF185 or. BF255 BF195 BF194 BF238 BF237 BC149 or. BC239 BC149 or. BC239 BC181 BC181 AC187 AC188 AC187 AC188 AD162
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz
Tuned circuits 7 AM circuit(s)     11 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details Changer (Record changer)
Power type and voltage Alternating Current supply (AC) / 110; 220 Volt
Loudspeaker 2 Loudspeakers
Power out 8 W (unknown quality)
from Radiomuseum.org Model: Merano 3 Ch= CS160MS - Grundig Radio-Vertrieb, RVF,
Material Wooden case
Shape Console with Push Buttons.
Dimensions (WHD) 1560 x 680 x 360 mm / 61.4 x 26.8 x 14.2 inch
Notes Das Gerät Merano 3 basiert auf dem Chassis CS160MS. Ein Stereo- Decoder (Typ 10) ist eingebaut.Als Plattenspieler ist das Phono-Chassis Grundig Automatic 36 mit dem Kristallsystem 22GP200 eingebaut. Die Gehäuseausführungen sind Edelholz hell mattiert oder Schleiflack weiss.
Net weight (2.2 lb = 1 kg) 38 kg / 83 lb 11.2 oz (83.7 lb)
External source of data Erb
Source of data Handbuch VDRG 1970/1971
Literature/Schematics (1) -- Original-techn. papers.
