Musikgerät RF120; Grundig Radio- (ID = 37884) Radio
Grundig Radio-: Musikgerät RF120 [Radio] ID = 37884 399x230
Select picture or schematic to display from thumbnails on the right and click for download.
For model Musikgerät RF120, Grundig (Radio-Vertrieb, RVF, Radiowerke):
ebay

Country:  Germany
Manufacturer / Brand:  Grundig (Radio-Vertrieb, RVF, Radiowerke)
alternative name

Grundig Portugal || Grundig USA / Lextronix
Year: 1966/1967 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: ECC85 ECH81 EAF801 ECL86
Semiconductors (the count is only for transistors) AA113 AA113
Main principle Super-Heterodyne (Super in general); ZF/IF 460/10700 kHz
Tuned circuits 6 AM circuit(s)     10 FM circuit(s)
Wave bands Broadcast, Long Wave and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 2.5 W (unknown quality)
from Radiomuseum.org Model: Musikgerät RF120 - Grundig Radio-Vertrieb, RVF,
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 530 x 290 x 190 mm / 20.9 x 11.4 x 7.5 inch
Notes

Grundig Musikgerät RF 120.
Klangwaage
Edelholzgehäuse mitteldunkel hochglanzpoliert oder Nußbaum natur mattiert.

Net weight (2.2 lb = 1 kg) 6.4 kg / 14 lb 1.6 oz (14.097 lb)
Price in first year of sale 270.00 DM
Collectors' prices
External source of data erb
Source of data Handbuch VDRG 1966/1967
Mentioned in Taxliste Franzis Verlag
Literature/Schematics (1) -- Original prospect or advert (Grundig Katalog 1967 - Schaufenster - Seite 13)
Literature/Schematics (2) -- Original-techn. papers.
