Grundig Radio-: Ocean-Boy 1000 Transistor 2000 [Radio] ID = 1071902 797x520

Select picture or schematic to display from thumbnails on the right and click for download.

For model Ocean-Boy 1000 Transistor (TR) 2000 Skala mit Sendernamen, Grundig (Radio-Vertrieb, RVF, Radiowerke):
Picture from an ended ebay auction № 190572370998, created by holzhacker49

Country:

Germany

Manufacturer / Brand:

Grundig (Radio-Vertrieb, RVF, Radiowerke)

alternative name

Grundig Portugal || Grundig USA / Lextronix

Year: 1971–1973

Category: Broadcast Receiver - or past WW2 Tuner

Semiconductors (the count is only for transistors)

13: BF314 BF241 BF240 BF241 BF241 BF240 BF241 BC309 BC238 BC338 or. GC223 or. BC223 AD157 AD156 BC238

Main principle	to an article Superheterodyne (common); ZF/IF 460/10700 kHz
Tuned circuits	7 AM circuit(s) 10 FM circuit(s)
Wave bands	Broadcast, Long Wave, more than 2 x SW plus FM or UHF.
Details
Power type and voltage	Line / Batteries (any type) / 110-127; 220-240 / 6×1,5 Volt
Loudspeaker	Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out	2 W (unknown quality)
from Radiomuseum.org	Model: Ocean-Boy 1000 Transistor 2000 [Skala mit Sendernamen] - Grundig Radio-Vertrieb, RVF,
Material	Modern plastics (no Bakelite or Catalin)
Shape	Portable set > 8 inch (also usable without mains)
Dimensions (WHD)	380 x 210 x 90 mm / 15 x 8.3 x 3.5 inch
Notes	6 KW-Bänder. Ausgangsleistung bei Netzbetrieb: 4 W. Siehe auch Exportversion Transistor 2000. 2 Ausführungen: nußbaumfärbiges Lautsprechergitter. schwarz mit alufärbigem Lautsprechergitter.
Net weight (2.2 lb = 1 kg)	3.8 kg / 8 lb 5.9 oz (8.37 lb)
Price in first year of sale	418.00 DM
External source of data	Erb
Source of data	Handbuch VDRG 1971/1972
Literature/Schematics (1)	-- Original-techn. papers.

All listed radios etc. from Grundig (Radio-Vertrieb, RVF, Radiowerke)
Here you find 6061 models, 5286 with images and 4091 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.

Forum contributions about this model

Grundig Radio-: Ocean-Boy 1000 Transistor 2000

Threads: 1 | Posts: 2

Hits: 833 Replies: 1

grundig: [Markt | Verschenke ] Grundig OceanBoy 1000 TR 2000

Roland Langfeld
16.Mar.18

grundig: [Markt | Verschenke ] Grundig OceanBoy 1000 TR 2000

Liebe Sammlerkollegen,

ich verschenke einen Grundig OceanBoy 1000 TR2000 zum Schlachten bzw. als Teileträger. Das Gerät hat keinen Empfang, nur der Endverstärker rauscht leise. Tasten sind schwergängig, Antennenspitze ist mit einem Reissnagel geflickt, Batteriefach ist sauber.

Abzuholen in Frankfurt (Main)

Roland Langfeld

Roland Langfeld
16.Mar.18

grundig: [Markt | Verschenke ] Grundig OceanBoy 1000 TR 2000

Der OceanBoy ist vergeben !

Das Angebot ist hiermit beendet,

Roland Langfeld
