Ocean Boy 350

Ocean Boy 350; Grundig Radio- (ID = 970963) Radio Ocean Boy 350; Grundig Radio- (ID = 970964) Radio
Ocean Boy 350; Grundig Radio- (ID = 970965) Radio Ocean Boy 350; Grundig Radio- (ID = 970966) Radio
Ocean Boy 350; Grundig Radio- (ID = 970967) Radio Ocean Boy 350; Grundig Radio- (ID = 970968) Radio
Ocean Boy 350; Grundig Radio- (ID = 970969) Radio Ocean Boy 350; Grundig Radio- (ID = 970971) Radio
Use red slider bar for more.
Ocean Boy 350; Grundig Radio- (ID = 970963) Radio
Grundig Radio-: Ocean Boy 350 [Radio] ID = 970963 933x548
Select picture or schematic to display from thumbnails on the right and click for download.
For model Ocean Boy 350, Grundig (Radio-Vertrieb, RVF, Radiowerke):
Thanks for technical assistance Első Zalai Rádiómúzeum Alapítvány ( radio-muzeum.hu), First Zala County Radio Museum Foundation, Hungary, Zalaegerszeg.

Country:  Germany
Manufacturer / Brand:  Grundig (Radio-Vertrieb, RVF, Radiowerke)
alternative name

Grundig Portugal || Grundig USA / Lextronix
Year: 2002 ? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Superheterodyne (common)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Batteries / addl. power jack / 4 × 1,5 / 6 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 0.8 W (unknown quality)
from Radiomuseum.org Model: Ocean Boy 350 - Grundig Radio-Vertrieb, RVF,
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 210 x 115 x 55 mm / 8.3 x 4.5 x 2.2 inch
Notes Grundig Ocean Boy 350, SW range 5950 - 15600 kHz
Ext. power jack: DC 6 V. Portable with Clock. 4 × 5 program presets.
Weight including batteries.
Net weight (2.2 lb = 1 kg) 0.650 kg / 1 lb 6.9 oz (1.432 lb)
Price in first year of sale 60.00 EUR

Model page created by Sandor Selyem-Tóth. See "Data change" for further contributors.



All listed radios etc. from Grundig (Radio-Vertrieb, RVF, Radiowerke)
Here you find 6064 models, 5290 with images and 4093 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
