Oszillograph G 3/13

• Country
• Germany

• Manufacturer / Brand
• Grundig (Radio-Vertrieb, RVF, Radiowerke); Fürth/Bayern

• Year
• 1966 ?

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 107358

• • alternative name: Grundig Portugal || Grundig USA / Lextronix

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 11

• Valves / Tubes
• EF184 EF184 PFL200 PFL200 PCF80 PCF80 PCF80 PCC88 ECC82 DY86 DG13-32

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 110; 220 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: Oszillograph G 3/13 - Grundig Radio-Vertrieb, RVF,

• Dimensions (WHD)
• 205 x 330 x 460 mm / 8.1 x 13 x 18.1 inch

• Net weight (2.2 lb = 1 kg)
• 11.5 kg / 25 lb 5.3 oz (25.33 lb)

• Mentioned in
• -- Original prospect or advert

• Author
• Model page created by Hugo Sneyers. See "Data change" for further contributors.
