• Year
  • 1980
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 134309
    • alternative name: Grundig Portugal || Grundig USA / Lextronix

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 3
  • Wave bands
  • - without
  • Details
  • Record Player (not changer)
  • Power type and voltage
  • Alternating Current supply (AC) / 110; 127; 220; 240 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Plattenspieler PS 2000 - Grundig Radio-Vertrieb, RVF,
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 420 x 141 x 348 mm / 16.5 x 5.6 x 13.7 inch
  • Notes
  • 1 IC: NE532V
    System Super M 400 II
    Gleichstrommotor mit Direct Control
    Drehzahl 33 und 45 U/min, elektronisch umschaltbar.
  • Literature/Schematics (1)
  • -- Original-techn. papers.
  • Author
  • Model page created by Josef Pilz. See "Data change" for further contributors.
