Radio-Recorder RR300 FM und MW
Use red slider bar for more.
Grundig Radio-: Radio-Recorder RR300 [Radio] ID = 1867767 1280x853
Select picture or schematic to display from thumbnails on the right and click for download.
|
|
||||
|
alternative name
|
Grundig Portugal || Grundig USA / Lextronix | ||||
|---|---|---|---|---|---|
| Year: 1990 ?? | Category: Broadcast Receiver - or past WW2 Tuner | ||||
| Semiconductors (the count is only for transistors) | Semiconductors present. |
| Main principle | Superheterodyne (common) |
|---|---|
| Wave bands | Broadcast (BC) and FM or UHF. |
| Details | Cassette-Recorder or -Player |
| Power type and voltage | Line / Batteries (any type) / AC: 50/60 Hz, 230 / D: 6 x 1,5 Volt |
| Loudspeaker | 2 Loudspeakers / Ø 9 cm = 3.5 inch |
| Power out | |
| from Radiomuseum.org | Model: Radio-Recorder RR300 [FM und MW] - Grundig Radio-Vertrieb, RVF, |
| Material | Modern plastics (no Bakelite or Catalin) |
| Shape | Portable set > 8 inch (also usable without mains) |
| Dimensions (WHD) | 420 x 170 x 140 mm / 16.5 x 6.7 x 5.5 inch |
| Notes | Erhältlich in verschiedenen Gehäusefarben (schwarz und rot bekannt). Siehe auch Modell RR300L mit FM, MW und LW, sowie RR300 aus 1979. |
| Net weight (2.2 lb = 1 kg) | 2 kg / 4 lb 6.5 oz (4.405 lb) |
Model page created by Manuel Albano Neves. See "Data change" for further contributors.
