Rauschgenerator 370

Rauschgenerator 370; Grundig Radio- (ID = 1697053) Equipment

Rauschgenerator 370; Grundig Radio- (ID = 2399253) Equipment

Rauschgenerator 370; Grundig Radio- (ID = 2399254) Equipment

Rauschgenerator 370; Grundig Radio- (ID = 2399255) Equipment

Rauschgenerator 370; Grundig Radio- (ID = 2399256) Equipment
Rauschgenerator 370; Grundig Radio- (ID = 2399252) Equipment
Use red slider bar for more.
Rauschgenerator 370; Grundig Radio- (ID = 2399252) Equipment
Grundig Radio-: Rauschgenerator 370 [Equipment] ID = 2399252 1220x1889
Select picture or schematic to display from thumbnails on the right and click for download.
For model Rauschgenerator 370, Grundig (Radio-Vertrieb, RVF, Radiowerke):
picture from manual

Country:  Germany
Manufacturer / Brand:  Grundig (Radio-Vertrieb, RVF, Radiowerke)
alternative name

Grundig Portugal || Grundig USA / Lextronix
Year: 1955 ?? Category: Service- or Lab Equipment
Valves / Tubes 1: 5722 EUXII 100E1
Semiconductors (the count is only for transistors) B150C15k
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 110; 220 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Rauschgenerator 370 - Grundig Radio-Vertrieb, RVF,
Material Metal case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 200 x 285 x 135 mm / 7.9 x 11.2 x 5.3 inch
Net weight (2.2 lb = 1 kg) 5.5 kg / 12 lb 1.8 oz (12.115 lb)
Mentioned in Lange, Schaltungen der Funkindustrie (Band 5, Seite 147)
Literature/Schematics (1) -- Original-techn. papers.

Model page created by a member from D. See "Data change" for further contributors.
