RC-Generator TG40

RC-Generator TG40; Grundig Radio- (ID = 2067443) Equipment

RC-Generator TG40; Grundig Radio- (ID = 2067444) Equipment

RC-Generator TG40; Grundig Radio- (ID = 2067445) Equipment

RC-Generator TG40; Grundig Radio- (ID = 2067446) Equipment
RC-Generator TG40; Grundig Radio- (ID = 2453504) Equipment RC-Generator TG40; Grundig Radio- (ID = 2453506) Equipment
RC-Generator TG40; Grundig Radio- (ID = 2453510) Equipment RC-Generator TG40; Grundig Radio- (ID = 2453511) Equipment
RC-Generator TG40; Grundig Radio- (ID = 431102) Equipment RC-Generator TG40; Grundig Radio- (ID = 2453505) Equipment
RC-Generator TG40; Grundig Radio- (ID = 2453507) Equipment RC-Generator TG40; Grundig Radio- (ID = 2453508) Equipment
RC-Generator TG40; Grundig Radio- (ID = 2453509) Equipment RC-Generator TG40; Grundig Radio- (ID = 2453512) Equipment
Use red slider bar for more.
RC-Generator TG40; Grundig Radio- (ID = 2453504) Equipment
Grundig Radio-: RC-Generator TG40 [Equipment] ID = 2453504 1400x670
Select picture or schematic to display from thumbnails on the right and click for download.
For model RC-Generator TG40, Grundig (Radio-Vertrieb, RVF, Radiowerke):
eigene Sammlung

Country:  Germany
Manufacturer / Brand:  Grundig (Radio-Vertrieb, RVF, Radiowerke)
alternative name

Grundig Portugal || Grundig USA / Lextronix
Year: 1973 Category: Service- or Lab Equipment
Semiconductors (the count is only for transistors) Semiconductors present.
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 110; 220 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: RC-Generator TG40 - Grundig Radio-Vertrieb, RVF,
Material Metal case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 300 x 112 x 170 mm / 11.8 x 4.4 x 6.7 inch
Notes

Frequenzbereich 10 Hz bis 1 MHz, Linearskala, Ausgangsspannung 0,1 mV bis 6,33 V, 10-dB-Grobteiler in sieben Schritten.

Flachskala, potentialfreier Ausgang.

Net weight (2.2 lb = 1 kg) 3 kg / 6 lb 9.7 oz (6.608 lb)
Price in first year of sale 398.00 DM
Mentioned in Funkschau (4.1976)
Literature/Schematics (1) -- Original prospect or advert (Grundig Messgeräteneuheiten 1973)

Model page created by Karlheinz Fischer. See "Data change" for further contributors.
