HiFi-Receiver 30

• Country
• Germany

• Manufacturer / Brand
• Grundig (Radio-Vertrieb, RVF, Radiowerke)

• Year
• 1976–1978

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 119165

• • alternative name: Grundig Portugal || Grundig USA / Lextronix

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 80

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast (BC) and FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 110; 130; 220; 240 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 60 W (unknown quality)

• Material
• Metal case

• from Radiomuseum.org
• Model: HiFi-Receiver 30 - Grundig Radio-Vertrieb, RVF,

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 540 x 155 x 325 mm / 21.3 x 6.1 x 12.8 inch

• Notes
• ICs: 9.
  Ausgangsleistung: 2× 50 W (Musik) bei Stereo bzw. 4× 30 W (Musik) bei 2-Raum-Stereo; Steuerung zum Teil über Sensortasten. 7 UKW-Speicherplätze.

• Net weight (2.2 lb = 1 kg)
• 11.2 kg / 24 lb 10.7 oz (24.67 lb)

• Source of data
• Handbuch VDRG 1976/1977

• Author
• Model page created by Peter Böhm. See "Data change" for further contributors.
