Record-Boy 210

Record-Boy 210; Grundig Radio- (ID = 843305) Radio

Record-Boy 210; Grundig Radio- (ID = 843306) Radio

Record-Boy 210; Grundig Radio- (ID = 843307) Radio

Record-Boy 210; Grundig Radio- (ID = 843309) Radio

Record-Boy 210; Grundig Radio- (ID = 843310) Radio
Record-Boy 210; Grundig Radio- (ID = 959366) Radio Record-Boy 210; Grundig Radio- (ID = 959359) Radio
Record-Boy 210; Grundig Radio- (ID = 959360) Radio Record-Boy 210; Grundig Radio- (ID = 959364) Radio
Record-Boy 210; Grundig Radio- (ID = 959365) Radio Record-Boy 210; Grundig Radio- (ID = 1107407) Radio
Use red slider bar for more.
Record-Boy 210; Grundig Radio- (ID = 959366) Radio
Grundig Radio-: Record-Boy 210 [Radio] ID = 959366 703x586
Select picture or schematic to display from thumbnails on the right and click for download.
For model Record-Boy 210, Grundig (Radio-Vertrieb, RVF, Radiowerke)

Country:  Germany
Manufacturer / Brand:  Grundig (Radio-Vertrieb, RVF, Radiowerke)
alternative name

Grundig Portugal || Grundig USA / Lextronix
Year: 1970 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 9: AF178 AF124 AF121 AF126 AF126 AC151 AC151 AC178 AC179
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz
Tuned circuits 7 AM circuit(s)     10 FM circuit(s)
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Dry Batteries / 2 x 4,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 1 W (unknown quality)
from Radiomuseum.org Model: Record-Boy 210 - Grundig Radio-Vertrieb, RVF,
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Notes Der Record-Boy 210 ist ein Reiseempfänger für den Empfang von MW und UKW.
Anschlußbuchsen für ein externes Netzteil und für einen Kopfhörer sind vorhanden.
Source of data -- Original-techn. papers.

Model page created by Wolfgang MICHAEL. See "Data change" for further contributors.
