Record-Boy Luxus LW208

Record-Boy Luxus LW208; Grundig Radio- (ID = 843688) Radio

Record-Boy Luxus LW208; Grundig Radio- (ID = 843689) Radio

Record-Boy Luxus LW208; Grundig Radio- (ID = 843690) Radio

Record-Boy Luxus LW208; Grundig Radio- (ID = 843696) Radio

Record-Boy Luxus LW208; Grundig Radio- (ID = 843691) Radio

Record-Boy Luxus LW208; Grundig Radio- (ID = 843692) Radio

Record-Boy Luxus LW208; Grundig Radio- (ID = 843693) Radio

Record-Boy Luxus LW208; Grundig Radio- (ID = 843694) Radio

Record-Boy Luxus LW208; Grundig Radio- (ID = 843695) Radio
Use red slider bar for more.
Record-Boy Luxus LW208; Grundig Radio- (ID = 843688) Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Germany
Manufacturer / Brand:  Grundig (Radio-Vertrieb, RVF, Radiowerke)
alternative name

Grundig Portugal || Grundig USA / Lextronix
Year: 1969 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 9: BF185 BF184 BF185 BF184 BF185 BC108 BC181 AC187 AC188
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz
Tuned circuits 7 AM circuit(s)     10 FM circuit(s)
Wave bands Broadcast, Long Wave and FM or UHF.
Details
Power type and voltage Dry Batteries / 2 x 4,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 1 W (unknown quality)
from Radiomuseum.org Model: Record-Boy Luxus LW208 - Grundig Radio-Vertrieb, RVF,
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Notes Der Record-Boy Luxus LW208 ist ein Reiseempfänger. Das Gerät hat eine Anschlußbuchse für ein externes Netzteil und eine Kopfhörerbuchse.
Source of data -- Original-techn. papers.

Model page created by Wolfgang MICHAEL. See "Data change" for further contributors.
