Record-Boy Luxus 208a

Record-Boy Luxus 208a; Grundig Radio- (ID = 392218) Radio

Record-Boy Luxus 208a; Grundig Radio- (ID = 392219) Radio

Record-Boy Luxus 208a; Grundig Radio- (ID = 392220) Radio

Record-Boy Luxus 208a; Grundig Radio- (ID = 392223) Radio

Record-Boy Luxus 208a; Grundig Radio- (ID = 392221) Radio

Record-Boy Luxus 208a; Grundig Radio- (ID = 392222) Radio

Record-Boy Luxus 208a; Grundig Radio- (ID = 843921) Radio

Record-Boy Luxus 208a; Grundig Radio- (ID = 843923) Radio

Record-Boy Luxus 208a; Grundig Radio- (ID = 843924) Radio
Use red slider bar for more.
Record-Boy Luxus 208a; Grundig Radio- (ID = 392218) Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Germany
Manufacturer / Brand:  Grundig (Radio-Vertrieb, RVF, Radiowerke)
alternative name

Grundig Portugal || Grundig USA / Lextronix
Year: 1968–1970 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 9: AF178 AF124 AF121 AF126 AF126 AC151 AC151 AC175 AC178
Main principle Superheterodyne (common); ZF/IF 460 kHz
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast, Long Wave and FM or UHF.
Details
Power type and voltage Dry Batteries / 2 × 4,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out
from Radiomuseum.org Model: Record-Boy Luxus 208a - Grundig Radio-Vertrieb, RVF,
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 270 x 170 x 70 mm / 10.6 x 6.7 x 2.8 inch
Net weight (2.2 lb = 1 kg) 2.1 kg / 4 lb 10 oz (4.626 lb)
Source of data Radiokatalog Band 1, Ernst Erb
Literature/Schematics (1) -- Original-techn. papers.
