RTV650 U

RTV650 U; Grundig Radio- (ID = 301610) Radio RTV650 U; Grundig Radio- (ID = 301611) Radio
RTV650 U; Grundig Radio- (ID = 301613) Radio RTV650 U; Grundig Radio- (ID = 301615) Radio
RTV650 U; Grundig Radio- (ID = 301616) Radio RTV650 U; Grundig Radio- (ID = 301619) Radio
RTV650 U; Grundig Radio- (ID = 301621) Radio RTV650 U; Grundig Radio- (ID = 301623) Radio
Use red slider bar for more.
RTV650 U; Grundig Radio- (ID = 301610) Radio
Grundig Radio-: RTV650 U [Radio] ID = 301610 640x480
Select picture or schematic to display from thumbnails on the right and click for download.
For model RTV650 U, Grundig (Radio-Vertrieb, RVF, Radiowerke)

Country:  Germany
Manufacturer / Brand:  Grundig (Radio-Vertrieb, RVF, Radiowerke)
alternative name

Grundig Portugal || Grundig USA / Lextronix
Year: 1969 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 53:
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz; Export model
Tuned circuits 10 AM circuit(s)     17 FM circuit(s)
Wave bands Broadcast, (BC) Long Wave (LW), 2 x SW and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 117 Volt
Loudspeaker - This model requires external speaker(s).
Power out 40 W (undistorted)
from Radiomuseum.org Model: RTV650 U - Grundig Radio-Vertrieb, RVF,
Material Wooden case
Shape Book-shelf unit.
Dimensions (WHD) 600 x 140 x 310 mm / 23.6 x 5.5 x 12.2 inch
Notes

Grundig RTV650 U ist ein Exportmodell für Nordamerika. Siehe auch RTV650.

Net weight (2.2 lb = 1 kg) 13.5 kg / 29 lb 11.8 oz (29.736 lb)

Model page created by Bernhard Nagel. See "Data change" for further contributors.
