• Country
• Germany

• Manufacturer / Brand
• Grundig (Radio-Vertrieb, RVF, Radiowerke)

• Year
• 1975–1977

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 131259

• • alternative name: Grundig Portugal || Grundig USA / Lextronix

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 96

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Details
• Changer (Record changer)

• Power type and voltage
• Alternating Current supply (AC) / 110; 130; 220; 240 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Material
• Various materials

• from Radiomuseum.org
• Model: Studio 2240 HiFi Quadro - Grundig Radio-Vertrieb, RVF,

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 670 x 170 x 400 mm / 26.4 x 6.7 x 15.7 inch

• Notes
• 3 Ausführungen:
  Studio 2240 = Gehäuse schwarz
  Studio 2240a = Gehäuse und Seitenteile bronze
  Studio 2240a = Gehäuse schwarz und Seitenteile bronze.
  ICs: 6.
  HiFi-Studio. Ausgangsleistung: 4× 30 W (Musik); CD-4-Demodulator nachrüstbar;
  Phono-Chassis = Dual 1228 mit Magnetsystem Shure M95G-LM.

• Source of data
• Handbuch VDRG 1976/1977

• Mentioned in
• Handbuch VDRG 1975/1976

• Author
• Model page created by Bernd P. Kieck. See "Data change" for further contributors.
