Super Color 1830

• Country
• Germany

• Manufacturer / Brand
• Grundig (Radio-Vertrieb, RVF, Radiowerke)

• Year
• 1978 ?

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 246971

• • alternative name: Grundig Portugal || Grundig USA / Lextronix

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 1

• Valves / Tubes
• 470HJB22

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• VHF incl. FM and/or UHF (see notes for details)

• Details
• Radio Control (+Remote Wire etc)

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Super Color 1830 - Grundig Radio-Vertrieb, RVF,

• Shape
• Tablemodel with Push Buttons.

• Notes

• Grundig 47cm Portable Color TV Modell Super Color 1830.
  Tele-Pilot 8 zur drahtlosen Fernwahl von 8 Programmen mit Leuchtdiodenanzeige.
  Automatischer Sendersuchlauf mit AFC, Allbereich VHF-UHF Tuner
  Gehäuseausführug in Weiss, Gelb, Rot oder Metallic-Hell.


• Price in first year of sale
• 1,398.00 DM

• Source of data
• -- Original prospect or advert

• Mentioned in
• Phora Katalog 1978

• Literature/Schematics (1)
• Grundig Service Unterlagen

• Author
• Model page created by Josef Pilz. See "Data change" for further contributors.
