Super-Color 6025b

Super-Color 6025b; Grundig Radio- (ID = 2352951) Television

Super-Color 6025b; Grundig Radio- (ID = 2352952) Television

Super-Color 6025b; Grundig Radio- (ID = 2352953) Television

Super-Color 6025b; Grundig Radio- (ID = 2352954) Television

Super-Color 6025b; Grundig Radio- (ID = 2352955) Television

Super-Color 6025b; Grundig Radio- (ID = 2352956) Television

Super-Color 6025b; Grundig Radio- (ID = 2352957) Television

Super-Color 6025b; Grundig Radio- (ID = 2352958) Television

Super-Color 6025b; Grundig Radio- (ID = 2352959) Television

Super-Color 6025b; Grundig Radio- (ID = 2352960) Television
Super-Color 6025b; Grundig Radio- (ID = 2074254) Television Super-Color 6025b; Grundig Radio- (ID = 158741) Television
Super-Color 6025b; Grundig Radio- (ID = 158743) Television Super-Color 6025b; Grundig Radio- (ID = 158739) Television
Super-Color 6025b; Grundig Radio- (ID = 158740) Television Super-Color 6025b; Grundig Radio- (ID = 158742) Television
Use red slider bar for more.
Super-Color 6025b; Grundig Radio- (ID = 2074254) Television
Grundig Radio-: Super-Color 6025b [Television] ID = 2074254 990x784
Select picture or schematic to display from thumbnails on the right and click for download.
For model Super-Color 6025b, Grundig (Radio-Vertrieb, RVF, Radiowerke):
Bild aus Grundig Technische Informationen 3/75

Country:  Germany
Manufacturer / Brand:  Grundig (Radio-Vertrieb, RVF, Radiowerke)
alternative name

Grundig Portugal || Grundig USA / Lextronix
Year: 1977 Category: Television Receiver (TV) or Monitor
Valves / Tubes 1: A66-500X
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Superheterodyne (common); ZF/IF 38900/5500 kHz; 1 AF stage(s)
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 220-240V Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 8 cm = 3.1 inch
Power out 8 W (unknown quality)
from Radiomuseum.org Model: Super-Color 6025b - Grundig Radio-Vertrieb, RVF,
Material Wooden case
Notes

Bereiche: VHF und UHF. Das TV-Gerät besitzt eine Thyristoren-Zeilenendstufe.

UHF/VHF Allbereich Tuner

Net weight (2.2 lb = 1 kg) 60 kg / 132 lb 2.5 oz (132.159 lb)
Source of data -- Original-techn. papers.

Model page created by Alexander Fuchs. See "Data change" for further contributors.
