Super HiFi Box 850a

Super HiFi Box 850a; Grundig Radio- (ID = 1016087) Speaker-P Super HiFi Box 850a; Grundig Radio- (ID = 950687) Speaker-P
Super HiFi Box 850a; Grundig Radio- (ID = 1016086) Speaker-P
Use red slider bar for more.
Super HiFi Box 850a; Grundig Radio- (ID = 1016087) Speaker-P
Grundig Radio-: Super HiFi Box 850a [Speaker-P] ID = 1016087 933x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Super HiFi Box 850a, Grundig (Radio-Vertrieb, RVF, Radiowerke):
Eigenes Gerät, eigenes Bild

Country:  Germany
Manufacturer / Brand:  Grundig (Radio-Vertrieb, RVF, Radiowerke)
alternative name

Grundig Portugal || Grundig USA / Lextronix
Year: 1978 ? Category: Loudspeaker, headphone or earphone
Wave bands - without
Details
Power type and voltage No Power needed
Loudspeaker 3 Loudspeakers
Power out
from Radiomuseum.org Model: Super HiFi Box 850a - Grundig Radio-Vertrieb, RVF,
Material Wooden case
Shape Book-shelf unit.
Dimensions (WHD) 278 x 445 x 207 mm / 10.9 x 17.5 x 8.1 inch
Notes Grundig Super HiFi Box 850a professional;
Nennimpedanz: 4 Ohm
Frequenzumfang: 35 Hz - 26 kHz
Übergangsfrequenzen der Weiche: 900/4000 Hz
Nennbelastbarkeit: 50 W
Musikbelastbarkeit: 80 W
Bruttovolumen: 25,6 l
Gehäuse aus Holz-Pressmaterial.
Net weight (2.2 lb = 1 kg) 10 kg / 22 lb 0.4 oz (22.026 lb)
Collectors' prices
Mentioned in HiFi-Jahrbuch 9, Verlag G. Braun, Karlsruhe 1978, S. 10-148

Model page created by Michael Kolb. See "Data change" for further contributors.
