Super HiFi Professional Aktiv Box 40

Super HiFi Professional Aktiv Box 40; Grundig Radio- (ID = 967724) Speaker-P

Super HiFi Professional Aktiv Box 40; Grundig Radio- (ID = 967725) Speaker-P

Super HiFi Professional Aktiv Box 40; Grundig Radio- (ID = 967726) Speaker-P

Super HiFi Professional Aktiv Box 40; Grundig Radio- (ID = 967727) Speaker-P

Super HiFi Professional Aktiv Box 40; Grundig Radio- (ID = 967728) Speaker-P
Super HiFi Professional Aktiv Box 40; Grundig Radio- (ID = 2093655) Speaker-P Super HiFi Professional Aktiv Box 40; Grundig Radio- (ID = 2093656) Speaker-P
Super HiFi Professional Aktiv Box 40; Grundig Radio- (ID = 210068) Speaker-P Super HiFi Professional Aktiv Box 40; Grundig Radio- (ID = 210069) Speaker-P
Super HiFi Professional Aktiv Box 40; Grundig Radio- (ID = 210070) Speaker-P Super HiFi Professional Aktiv Box 40; Grundig Radio- (ID = 210071) Speaker-P
Super HiFi Professional Aktiv Box 40; Grundig Radio- (ID = 210072) Speaker-P Super HiFi Professional Aktiv Box 40; Grundig Radio- (ID = 2102280) Speaker-P
Super HiFi Professional Aktiv Box 40; Grundig Radio- (ID = 2102283) Speaker-P Super HiFi Professional Aktiv Box 40; Grundig Radio- (ID = 2102286) Speaker-P
Use red slider bar for more.
Super HiFi Professional Aktiv Box 40; Grundig Radio- (ID = 2093655) Speaker-P
Grundig Radio-: Super HiFi Professional Aktiv Box 40 [Speaker-P] ID = 2093655 1400x1895
Select picture or schematic to display from thumbnails on the right and click for download.
For model Super HiFi Professional Aktiv Box 40, Grundig (Radio-Vertrieb, RVF, Radiowerke):
Grundig Katalog 1979

Country:  Germany
Manufacturer / Brand:  Grundig (Radio-Vertrieb, RVF, Radiowerke)
alternative name

Grundig Portugal || Grundig USA / Lextronix
Year: 1979 ?? Category: Loudspeaker, headphone or earphone
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Audio-Amplification
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker 4 Loudspeakers
Power out 150 W (unknown quality)
from Radiomuseum.org Model: Super HiFi Professional Aktiv Box 40 - Grundig Radio-Vertrieb, RVF,
Material Wooden case
Shape Console with any shape - in general
Dimensions (WHD) 360 x 610 x 370 mm / 14.2 x 24 x 14.6 inch
Notes - Klirrfaktor der Verstärker >0,2% im Bereich 20-20.000Hz (typ. 0,05%)
- Fremdspannungsabstand 70/96dB (50 mW/Nennausgangsleistung)
- 1V Nenneingaangsspannung an 200 Ohm
- Eingangswiederstand 10 Ohm.
- Anzahl der Verstärker: 4
- Gesamt-Musik-/Nennleistung: 150/120 Watt
- Übertragungsbereich: 22 - 26.000 Hz.
- Übernahmefrequenzen der elektronischen Weichen: 200/500/5000 Hz.
- Anzahl d.Lautspr.: 1-Kallottenhochton / 1-Mittelton / 2-Tiefton
- Nettovolumen ca. 43 Liter

Gewicht bezieht sich auf eine Box.
Net weight (2.2 lb = 1 kg) 25 kg / 55 lb 1.1 oz (55.066 lb)
Source of data - - Data from my own collection

Model page created by Peter Böhm. See "Data change" for further contributors.
