HiFi-Receiver R25

HiFi-Receiver R25; Grundig Radio- (ID = 191386) Radio

HiFi-Receiver R25; Grundig Radio- (ID = 191387) Radio

HiFi-Receiver R25; Grundig Radio- (ID = 191388) Radio

HiFi-Receiver R25; Grundig Radio- (ID = 191389) Radio

HiFi-Receiver R25; Grundig Radio- (ID = 191390) Radio

HiFi-Receiver R25; Grundig Radio- (ID = 191391) Radio

HiFi-Receiver R25; Grundig Radio- (ID = 191392) Radio

HiFi-Receiver R25; Grundig Radio- (ID = 191393) Radio

HiFi-Receiver R25; Grundig Radio- (ID = 191394) Radio

HiFi-Receiver R25; Grundig Radio- (ID = 191395) Radio
HiFi-Receiver R25; Grundig Radio- (ID = 502505) Radio HiFi-Receiver R25; Grundig Radio- (ID = 317332) Radio
HiFi-Receiver R25; Grundig Radio- (ID = 502503) Radio HiFi-Receiver R25; Grundig Radio- (ID = 188273) Radio
HiFi-Receiver R25; Grundig Radio- (ID = 502499) Radio HiFi-Receiver R25; Grundig Radio- (ID = 502500) Radio
HiFi-Receiver R25; Grundig Radio- (ID = 502502) Radio HiFi-Receiver R25; Grundig Radio- (ID = 502504) Radio
HiFi-Receiver R25; Grundig Radio- (ID = 502506) Radio HiFi-Receiver R25; Grundig Radio- (ID = 1062170) Radio
Use red slider bar for more.
HiFi-Receiver R25; Grundig Radio- (ID = 502505) Radio
Grundig Radio-: HiFi-Receiver R25 [Radio] ID = 502505 900x466
Select picture or schematic to display from thumbnails on the right and click for download.
For model HiFi-Receiver R25, Grundig (Radio-Vertrieb, RVF, Radiowerke):
Sammlung

Country:  Germany
Manufacturer / Brand:  Grundig (Radio-Vertrieb, RVF, Radiowerke)
alternative name

Grundig Portugal || Grundig USA / Lextronix
Year: 1977/1978 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 35:
Main principle Super-Heterodyne (Super in general)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110-130; 220-240 Volt
Loudspeaker - This model requires external speaker(s).
Power out
from Radiomuseum.org Model: HiFi-Receiver R25 - Grundig Radio-Vertrieb, RVF,
Material Metal case
Shape Book-shelf unit.
Dimensions (WHD) 550 x 145 x 310 mm / 21.7 x 5.7 x 12.2 inch
Notes 2 Ausführungen: Gehäuse metallic oder schwarz
Ausgangsleistung: 2× 30 W (Sinus) nach DIN 45500. Rauschfilter linear und contur, MPX-Filter und Mutingtaste. Antenneneingang 75 und 300 Ohm. UKW: 87,5···108 MHz.
Net weight (2.2 lb = 1 kg) 10 kg / 22 lb 0.4 oz (22.026 lb)
Collectors' prices
Source of data Handbuch VDRG 1977/1978
Mentioned in -- Original prospect or advert (HiFi & TV Januar/Februar 1978)
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Carlos A. Pieroni-García. See "Data change" for further contributors.
