For model SV80 a, Grundig (Radio-Vertrieb, RVF, Radiowerke)

Country:  Germany
Manufacturer / Brand:  Grundig (Radio-Vertrieb, RVF, Radiowerke)
alternative name

Grundig Portugal || Grundig USA / Lextronix
Year: 1966/1967 Category: Audio Amplifier or -mixer
Semiconductors (the count is only for transistors) 29:
Main principle Audio-Amplification
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 110-240 Volt
Loudspeaker - This model requires external speaker(s).
Power out
from Radiomuseum.org Model: SV80 a - Grundig Radio-Vertrieb, RVF,
Material Wooden case
Shape Book-shelf unit.
Dimensions (WHD) 390 x 150 x 270 mm / 15.4 x 5.9 x 10.6 inch
Notes 15 Dioden laut VDRG Handbuch, doch der SV80 wurde ständig weiterentwickelt, da die Endstufen bei Überlastung schnell zerstört wurden. . Die Diodenbestückung wurde oft geändert. Siehe geladenen Schaltplan aus Grundig TI 5.1966 und Variante 1965
Net weight (2.2 lb = 1 kg) 9 kg / 19 lb 13.2 oz (19.824 lb)
Collectors' prices
External source of data erb
Source of data Handbuch VDRG 1966/1967
Literature/Schematics (1) -- Original-techn. papers.
