SV80M; Grundig Radio- (ID = 34410) Ampl/Mixer
Grundig Radio-: SV80M [Ampl/Mixer] ID = 34410 800x600
Select picture or schematic to display from thumbnails on the right and click for download.
For model SV80M, Grundig (Radio-Vertrieb, RVF, Radiowerke)

Country:  Germany
Manufacturer / Brand:  Grundig (Radio-Vertrieb, RVF, Radiowerke)
alternative name

Grundig Portugal || Grundig USA / Lextronix
Year: 1966–1969 Category: Audio Amplifier or -mixer
Semiconductors (the count is only for transistors) 29:
Main principle Audio-Amplification
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 110; 130; 220; 240 Volt
Loudspeaker - This model requires external speaker(s).
Power out 60 W (undistorted)
from Radiomuseum.org Model: SV80M - Grundig Radio-Vertrieb, RVF,
Material Wooden case
Shape Book-shelf unit.
Dimensions (WHD) 410 x 150 x 280 mm / 16.1 x 5.9 x 11 inch
Notes HiFi-Stereo-Verstärker mit 2 Endstufen je 30 W (Sinus). Anschlüsse für Kopfhörer, TA magn, TA kristall, Universal (AUX), Tuner, TB; Funktionen: Rauschen, Rumpeln, TB Monitor, Contour 1, Contour 2, Linear, Präsenz.
Net weight (2.2 lb = 1 kg) 9 kg / 19 lb 13.2 oz (19.824 lb)
Price in first year of sale 13'950.00 BFr
External source of data erb
Source of data Handbuch VDRG 1967/1968
Mentioned in -- Original prospect or advert (Grundig Katalog 1967 - Schaufenster - Seite 21)
