- Country
- Germany
- Manufacturer / Brand
- Grundig (Radio-Vertrieb, RVF, Radiowerke); Fürth/Bayern
- Year
- 1967
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 127670
-
- alternative name: Grundig Portugal || Grundig USA / Lextronix
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Number of Transistors
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Details
- Tape Recorder
- Power type and voltage
- Alternating Current supply (AC) / 110; 130; 220; 240; Volt
- Loudspeaker
- 2 Loudspeakers
- from Radiomuseum.org
- Model: TK240 - Grundig Radio-Vertrieb, RVF,
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 410 x 200 x 340 mm / 16.1 x 7.9 x 13.4 inch
- Notes
- Mono-Aufnahme (mit abschaltbarer Automatik) und Wiedergabe in Viertelspurtechnik, Tricktaste, eingebautes Mischpult, Bandgeschwindigkeit 9,5 und 4,75 cm/s.
- Net weight (2.2 lb = 1 kg)
- 13 kg / 28 lb 10.1 oz (28.634 lb)
- Mentioned in
- -- Original-techn. papers.
- Author
- Model page created by Heribert Jung. See "Data change" for further contributors.
