TK6L Elektronische Drehzahlregelung

TK6L; Grundig Radio- (ID = 1986051) R-Player

TK6L; Grundig Radio- (ID = 1985531) R-Player

TK6L; Grundig Radio- (ID = 1985534) R-Player

TK6L; Grundig Radio- (ID = 1986050) R-Player

TK6L; Grundig Radio- (ID = 1985650) R-Player

TK6L; Grundig Radio- (ID = 1985651) R-Player

TK6L; Grundig Radio- (ID = 1985652) R-Player

TK6L; Grundig Radio- (ID = 1985653) R-Player

TK6L; Grundig Radio- (ID = 1985654) R-Player

TK6L; Grundig Radio- (ID = 1985655) R-Player
TK6L; Grundig Radio- (ID = 1986385) R-Player TK6L; Grundig Radio- (ID = 1986384) R-Player
TK6L; Grundig Radio- (ID = 1016816) R-Player TK6L; Grundig Radio- (ID = 1986387) R-Player
TK6L; Grundig Radio- (ID = 1986370) R-Player TK6L; Grundig Radio- (ID = 1986383) R-Player
TK6L; Grundig Radio- (ID = 1986393) R-Player TK6L; Grundig Radio- (ID = 1986390) R-Player
TK6L; Grundig Radio- (ID = 1057961) R-Player TK6L; Grundig Radio- (ID = 1057963) R-Player
Use red slider bar for more.
TK6L; Grundig Radio- (ID = 1986385) R-Player
Grundig Radio-: TK6L [R-Player] ID = 1986385 1400x934
Select picture or schematic to display from thumbnails on the right and click for download.
For model TK6L Elektronische Drehzahlregelung, Grundig (Radio-Vertrieb, RVF, Radiowerke):
Die Spulen sind verriegelt, damit das Gerät stehend betrieben werden kann.

Country:  Germany
Manufacturer / Brand:  Grundig (Radio-Vertrieb, RVF, Radiowerke)
alternative name

Grundig Portugal || Grundig USA / Lextronix
Year: 1965–1968 Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) 15: OC306 OC304 AC116 AC117 AC122 TF78 BFY39 OA70
Main principle Audio-Amplification
Wave bands - without
Details Tape Recorder
Power type and voltage Line / Batteries (any type) / 110; 220 / 6 × 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 0.5 W (unknown quality)
from Radiomuseum.org Model: TK6L [Elektronische Drehzahlregelung] - Grundig Radio-Vertrieb, RVF,
Material Modern plastics (no Bakelite or Catalin)
Dimensions (WHD) 230 x 230 x 140 mm / 9.1 x 9.1 x 5.5 inch
Notes

(Halbleiterliste: nur einmal pro Typ)
Transistoren: OC306/2, 3× OC304, AC116, 5× AC117, 2× AC122, TF78, 2× BFY39; Dioden OA70, Z8K, 6× G580, 1103.
Zweispurgerät, Spulen-Ø 11 cm, Geschwindigkeiten 4,75/9,5 cm/s.
NF-Ausgangsleistung bei Netzbetrieb = 1,6 W.
Hergestellt in Irland.

Die Serviceunterlagen sind beim TK6L 1965

Net weight (2.2 lb = 1 kg) 6.3 kg / 13 lb 14 oz (13.877 lb)
Price in first year of sale 558.00 DM
External source of data erb
Source of data Handbuch VDRG 1966/1967
