For model TS246 HiFi, Grundig (Radio-Vertrieb, RVF, Radiowerke):
Gerät steht in einem Museum.

Country:  Germany
Manufacturer / Brand:  Grundig (Radio-Vertrieb, RVF, Radiowerke)
alternative name

Grundig Portugal || Grundig USA / Lextronix
Year: 1971/1972 Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) 13:
Main principle Audio-Amplification
Wave bands - without
Details Tape Recorder
Power type and voltage Alternating Current supply (AC) / 110; 220 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: TS246 HiFi - Grundig Radio-Vertrieb, RVF,
Material Modern plastics (no Bakelite or Catalin)
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 420 x 165 x 360 mm / 16.5 x 6.5 x 14.2 inch
Notes HiFi-Vierspur-Stereo. Bandgeschwindigkeiten: 9,5/19 cm/s; Spulen-Ø: 18 cm. Übertragungsbereich bei 19 cm/s: 40-16000 Hz. Für horizontale und vertikale Betriebslage geeignet.
Net weight (2.2 lb = 1 kg) 9.5 kg / 20 lb 14.8 oz (20.925 lb)
External source of data Erb
Source of data Handbuch VDRG 1971/1972
