Tuner T 5500
Grundig (Radio-Vertrieb, RVF, Radiowerke)
- Country
- Germany
- Manufacturer / Brand
- Grundig (Radio-Vertrieb, RVF, Radiowerke)
- Year
- 1991 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 133293
-
- alternative name: Grundig Portugal || Grundig USA / Lextronix
(c)2015 eBay-391069464485-netztaenzer
(c)2015 eBay-391069464485-netztaenzer
(c)2015 eBay-391069464485-netztaenzer
(c)2015 eBay-391069464485-netztaenzer
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 27
- Semiconductors
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast (BC) and FM or UHF.
- Power type and voltage
- Alternating Current supply (AC) / 230 Volt
- Loudspeaker
- - For headphones or amp.
- Material
- Metal case
- from Radiomuseum.org
- Model: Tuner T 5500 - Grundig Radio-Vertrieb, RVF,
- Shape
- Book-shelf unit.
- Notes
- 5 ICs.
- Mentioned in
- Original Grundig Service Unterlagen
- Author
- Model page created by Josef Pilz. See "Data change" for further contributors.
