Weltklang 2000

Weltklang 2000; Grundig Radio- (ID = 63509) Car Radio

Weltklang 2000; Grundig Radio- (ID = 63510) Car Radio

Weltklang 2000; Grundig Radio- (ID = 63511) Car Radio

Weltklang 2000; Grundig Radio- (ID = 63512) Car Radio

Weltklang 2000; Grundig Radio- (ID = 63513) Car Radio

Weltklang 2000; Grundig Radio- (ID = 63514) Car Radio
Weltklang 2000; Grundig Radio- (ID = 98783) Car Radio Weltklang 2000; Grundig Radio- (ID = 2135981) Car Radio
Weltklang 2000; Grundig Radio- (ID = 2281973) Car Radio Weltklang 2000; Grundig Radio- (ID = 2558181) Car Radio
Use red slider bar for more.
Weltklang 2000; Grundig Radio- (ID = 98783) Car Radio
Grundig Radio-: Weltklang 2000 [Car Radio] ID = 98783 863x259
Select picture or schematic to display from thumbnails on the right and click for download.
For model Weltklang 2000, Grundig (Radio-Vertrieb, RVF, Radiowerke)

Country:  Germany
Manufacturer / Brand:  Grundig (Radio-Vertrieb, RVF, Radiowerke)
alternative name

Grundig Portugal || Grundig USA / Lextronix
Year: 1967–1969 Category: Car Radio, perhaps also + sound player/recorder
Semiconductors (the count is only for transistors) 9: BF185 BF184 BF184 BF185 BF185 BF184 BC108 AD161 AD162 AA116 AA116 1N60 ST1
Main principle Superheterodyne (common); ZF/IF 460 kHz
Tuned circuits 8 AM circuit(s)     10 FM circuit(s)
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Storage Battery for all (e.g. for car radios and amateur radios) / 6; 12 Volt
Loudspeaker - This model requires external speaker(s).
Power out 4 W (unknown quality)
from Radiomuseum.org Model: Weltklang 2000 - Grundig Radio-Vertrieb, RVF,
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 170 x 40 x 160 mm / 6.7 x 1.6 x 6.3 inch
Notes Anschluss für Autotonbandgerät vorbereitet.
Net weight (2.2 lb = 1 kg) 1.2 kg / 2 lb 10.3 oz (2.643 lb)
Price in first year of sale 175.00 DM
External source of data erb
Source of data Handbuch VDRG 1967/1968
Mentioned in -- Original prospect or advert (Grundig Katalog 1967 - Schaufenster - Seite 31)
Literature/Schematics (1) Bauer-Katalog, Bamberg, 1968
