• Country
• Germany

• Manufacturer / Brand
• Grundig (Radio-Vertrieb, RVF, Radiowerke)

• Year
• 1970–1976

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 186684

• • alternative name: Grundig Portugal || Grundig USA / Lextronix

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 1

• Valves / Tubes

• Number of Transistors
• 55

• Semiconductors

• Wave bands
• - without

• Power type and voltage
• Line / Batteries (any type) / 110/220 V AC oder 24 V DC (21,5-32) Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: Zweikanaloszilloskop G10/13 Z - Grundig Radio-Vertrieb, RVF,

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 300 x 200 x 0 mm / 11.8 x 7.9 x 0 inch

• Notes
• Schirmfläche: 10cm X 8cm.

• Net weight (2.2 lb = 1 kg)
• 10 kg / 22 lb 0.4 oz (22.026 lb)

• Price in first year of sale
• 1,550.00 DM

• Mentioned in
• Funk-Technik (FT) (21/76 Seite 699)

• Literature/Schematics (1)
• Funk-Technik (FT) (13/1970, S. 482 / Neuvorstellung, Messe Hannover)

• Author
• Model page created by Egon Strampe. See "Data change" for further contributors.
