Zweikanaloszilloskop MO-50

Grundig (Radio-Vertrieb, RVF, Radiowerke)

  • Year
  • 1973
  • Category
  • Service- or Lab Equipment
  • Radiomuseum.org ID
  • 186702
    • alternative name: Grundig Portugal || Grundig USA / Lextronix

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 1
  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Wave bands
  • - without
  • Power type and voltage
  • Alternating Current supply (AC) / 110; 220 Volt
  • Loudspeaker
  • - - No sound reproduction output.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Zweikanaloszilloskop MO-50 - Grundig Radio-Vertrieb, RVF,
  • Shape
  • Tablemodel, low profile (big size).
  • Dimensions (WHD)
  • 360 x 150 x 470 mm / 14.2 x 5.9 x 18.5 inch
  • Notes
  • Schirmfläche: 10cm x 8cm.

    50 MHz Zweikanal-Oszilloskop, 12kV-Rechteckröhre, automatischt Triggerung mit LF-und HF-Filter, einmalige Triggerung mit Auslösesperre.

  • Net weight (2.2 lb = 1 kg)
  • 13 kg / 28 lb 10.1 oz (28.634 lb)
  • Price in first year of sale
  • 3,900.00 DM
  • Mentioned in
  • -- Original prospect or advert (Grundig Messgeräteneuheiten 1973)
  • Literature/Schematics (1)
  • - - Manufacturers Literature (Grundig Technische Informationen 4/1973)
  • Author
  • Model page created by Egon Strampe. See "Data change" for further contributors.
