• Country
• Great Britain (UK)

• Manufacturer / Brand
• Hacker Radio Ltd., Maidenhead

• Year
• 1964

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 109371

• Number of Transistors
• 11

• Semiconductors
• AF117 AF117 AF117 AF115 AF115 OC71 OC75 AC127 OC81D AC127 OC81

• Main principle
• Superheterodyne (common); ZF/IF 470 kHz

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• Dry Batteries / 2 x 9 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Power out
• 1.2 W (unknown quality)

• Material
• Leather / canvas / plastic - over other material

• from Radiomuseum.org
• Model: RP31SW - Hacker Radio Ltd., Maidenhead

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 12 x 8.75 x 4.5 inch / 305 x 222 x 114 mm

• Notes
• Elliptical loudspeaker 8 x 5 inch.

• Source of data
• -- Collector info (Sammler)

• Literature/Schematics (1)
• - - Manufacturers Literature

• Author
• Model page created by John Koster. See "Data change" for further contributors.
