• Year
  • 1928–1930
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 2249

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 3
  • Main principle
  • TRF with regeneration; 1 AF stage(s)
  • Tuned circuits
  • 1 AM circuit(s)
  • Wave bands
  • Broadcast (MW) and Long Wave.
  • Power type and voltage
  • Alternating Current supply (AC) / 110/220 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Überland und mehr W - Hagenuk N&K, Hanseatische App.
  • Shape
  • Tablemodel, high profile (upright - NOT Cathedral nor decorative).
  • Dimensions (WHD)
  • 310 x 230 x 135 mm / 12.2 x 9.1 x 5.3 inch
  • Notes
  • [560]
  • Price in first year of sale
  • 194.00 RM !
  • Circuit diagram reference
  • Röhren in FS-Bestückungstabellen
  • Picture reference
  • Das Modell ist im «Radiokatalog» (Erb) abgebildet.
