• Country
• Canada

• Manufacturer / Brand
• Hallicrafters Canada Ltd., The; Toronto, ON

• Year
• 1954 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 301310

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• 1U4 1L6 1U4 1U5 3V4

• Main principle
• Superhet with RF-stage; ZF/IF 455 kHz; 2 AF stage(s)

• Tuned circuits
• 7 AM circuit(s)

• Wave bands
• Broadcast, Long Wave and 2 x Short Wave.

• Power type and voltage
• Line / Batteries (any type) / Either 9 & 90 or AC or DC 105-120 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm

• Material
• Leather / canvas / plastic - over other material

• from Radiomuseum.org
• Model: TW-500C - Hallicrafters Canada Ltd., The

• Shape
• Portable set > 8 inch (also usable without mains)

• Notes

• The Halicrafters model TW-500C is a 5-tube line or battery powered portable radio. Covers the following rangers:


  Band	Frequency Range	Reception
  1	170 - 415 kHz	Longwave
  2	535 - 1620 kHz	Standard Broadcast
  3	2 - 6 MHz	Shortwave
  4	6 - 18 MHz	Shortwave

  Similar to USA model TW-500.

• Literature/Schematics (1)
• Radio College of Canada (RCC) (1955 Supplement 34)

• Author
• Model page created by Tom Seeger. See "Data change" for further contributors.
