Oscilloscope HM512-7 - Y01

HAMEG GmbH, Frankfurt

  • Year
  • 1975 ??
  • Category
  • Service- or Lab Equipment
  • Radiomuseum.org ID
  • 164532

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 1
  • Valves / Tubes
  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Wave bands
  • - without
  • Power type and voltage
  • Alternating Current supply (AC) / 220 Volt
  • Loudspeaker
  • - - No sound reproduction output.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Oscilloscope HM512-7 - Y01 - HAMEG GmbH, Frankfurt
  • Shape
  • Tablemodel, high profile (upright - NOT Cathedral nor decorative).
  • Dimensions (WHD)
  • 210 x 250 x 420 mm / 8.3 x 9.8 x 16.5 inch
  • Notes
  • Unterschied zwischen HM512-7 - Y01 und HM512-7 - Y02:
    Variante 2 zu HM512/7. Im Gegensatz zu Var.1 wird "X-MAGN.x5" am X-Pos.-Regler durch ziehen vorgenommen und die Hintergrundbeleuchtung über einen zusätzlichen 4-stufigen Schiebeschalter geregelt. Auch die Delay-Einstellung wurde geändert. Im Innern ist bei der Zeitbasisleiterplatte die Bezeichnung HM512/7 Y02 mit eingeätzt (bei der Var.1 dagegen HM512/7 Y01).
  • Net weight (2.2 lb = 1 kg)
  • 8.9 kg / 19 lb 9.7 oz (19.604 lb)
  • Author
  • Model page created by Dieter ADAM. See "Data change" for further contributors.
