Oszilloskop HM-512-8

Universal-Oszilloskop für Labor und Service.
2 Kanäle, Bandbreite 0-50MHz (-3dB), 0-65MHz (-6dB), Anstiegszeit ca.7ns.
Verzögerbare Zeitbasis, Verzögerunggsleitung, after Delay-Triggerung,
Triggerung ab 5mm Signalhöhe bis mind. 70MHz, in Stellung "HF" sogar über 100MHz.

Die Strahlröhre arbeitet mit einer Beschleunigungsspannung von 12kV.
Zusätzliche Leuchtdioden
für  Y-Überbereich/Overdrive, Triggereinsatz, Einzelbildauslösung und Delay-Betriebsart.

Alle Halbleiter-Typen können mehrfach vorhanden sein..

Net weight (2.2 lb = 1 kg) 9.4 kg / 20 lb 11.3 oz (20.705 lb)
