• Country
• Austria

• Manufacturer / Brand
• HEA; Wien

• Year
• 1975

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 166613

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 7

• Semiconductors
• BC304 BC149 BC149 BC159 BC727 BC149 BC148

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Cassette-Recorder or -Player

• Power type and voltage
• Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt

• Loudspeaker
• - For headphones or amp.

• from Radiomuseum.org
• Model: Cassettenspieler S24CW - HEA; Wien

• Shape
• Chassis only or for «building in»

• Notes
• Betrieb nur an ext. Autoradio möglich, keine eingebaute NF-Endstufe.

• Source of data
• -- Original prospect or advert

• Author
• Model page created by Rudolf Müller. See "Data change" for further contributors.
