Donauland UKW MW/UKW neu, Batterie-Netz

Donauland UKW MW/UKW neu, Batterie-Netz; HEA; Wien (ID = 778643) Radio Donauland UKW MW/UKW neu, Batterie-Netz; HEA; Wien (ID = 778636) Radio
Donauland UKW MW/UKW neu, Batterie-Netz; HEA; Wien (ID = 778639) Radio Donauland UKW MW/UKW neu, Batterie-Netz; HEA; Wien (ID = 778641) Radio
Donauland UKW MW/UKW neu, Batterie-Netz; HEA; Wien (ID = 778637) Radio Donauland UKW MW/UKW neu, Batterie-Netz; HEA; Wien (ID = 778638) Radio
Donauland UKW MW/UKW neu, Batterie-Netz; HEA; Wien (ID = 778640) Radio Donauland UKW MW/UKW neu, Batterie-Netz; HEA; Wien (ID = 778642) Radio
Donauland UKW MW/UKW neu, Batterie-Netz; HEA; Wien (ID = 2046343) Radio Donauland UKW MW/UKW neu, Batterie-Netz; HEA; Wien (ID = 2046345) Radio
Use red slider bar for more.
Donauland UKW MW/UKW neu, Batterie-Netz; HEA; Wien (ID = 778643) Radio
HEA; Wien: Donauland UKW MW/UKW neu, Batterie-Netz [Radio] ID = 778643 874x684
Select picture or schematic to display from thumbnails on the right and click for download.
For model Donauland UKW MW/UKW neu, Batterie-Netz, HEA; Wien

Country:  Austria
Manufacturer / Brand:  HEA; Wien
Year: 1964 ? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 11: AF121 AF125 AF126 AF126 AF126 AC125 AC125 AC127 AC132 AC125 AC128
Main principle Superheterodyne (common)
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Line / Batteries (any type) / 220/2 × 4,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Donauland UKW MW/UKW neu, Batterie-Netz - HEA; Wien
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 250 x 145 x 65 mm / 9.8 x 5.7 x 2.6 inch
Notes HEA baute in den 60iger Jahren eine ganze Reihe von verschiedenen Kofferempfänger für die Buchgemeinschaft Donauland ohne genaue Bezeichnung und Betitelung, nur mit dem Namen "Donauland".
Source of data Radiokatalog Band 2, Ernst Erb

Model page created by Hannes Wurnitsch. See "Data change" for further contributors.
