For model Jacky MW, HEA; Wien:
Hea Jacky

Country:  Austria
Manufacturer / Brand:  HEA; Wien
Year: 1963 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 7: AF127 AF127 AF127 AC125 AC125 AC127 AC132
Main principle Superheterodyne (common)
Tuned circuits 5 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Dry Batteries / 2 × 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Jacky [MW] - HEA; Wien
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 110 x 70 x 33 mm / 4.3 x 2.8 x 1.3 inch
Notes !!! Achtung, die Bezeichnung auf den Tasten bedeutet: S = Sprache, M = Musik und nicht wie oft irrtümlich angenommen wird KW und MW !!!
Net weight (2.2 lb = 1 kg) 0.2 kg / 0 lb 7 oz (0.441 lb)
Price in first year of sale 599.00 öS
External source of data E. Erb 3-907007-36-0
Source of data Radiokatalog Band 2, Ernst Erb
Literature/Schematics (1) -- Original-techn. papers.


All listed radios etc. from HEA; Wien
Here you find 195 models, 140 with images and 158 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.






Forum contributions about this model
HEA; Wien: Jacky
Threads: 1 | Posts: 1
Hits: 1997     Replies: 0
hea: HEA Jacky
Gerhard Heigl
17.Jul.02
  1 Baujahr: 1963, 5 Kreise, Gewicht: 0,2kg, Orig.Preis: 599S, Betrieb: 2x1,5V Mignon, Gehäuse Plastik, BHT: 110x70x33mm, 7Transistoren: 3xAF127, 2xAC125, AC127/132.
