• Country
• Germany

• Manufacturer / Brand
• Heliogen, Hermann Pawlik; Bad Blankenburg (GINOR)

• Year
• 1933 ?

• Category
• Radio module post 1925 (not a part, not a key)

• Radiomuseum.org ID
• 153139

Click on the schematic thumbnail to request the schematic as a free document.

• Main principle
• RF-Circuit or wave trap (separate, can also be an antenna with amp.)

• Wave bands
• Broadcast (MW) and Long Wave.

• Power type and voltage
• No Power needed

• Loudspeaker
• - - No sound reproduction output.

• Material
• Wooden case

• from Radiomuseum.org
• Model: Selektionskreis 1950 - Heliogen, Hermann Pawlik; Bad

• Shape
• Tablemodel, with any shape - general.

• Notes
• Selektionskreis mit Lautstärkenregelung.
  Nussbaumgehäuse.

• Price in first year of sale
• 29.00 RM

• Source of data
• -- Original prospect or advert

• Author
• Model page created by a member from D. See "Data change" for further contributors.
