• Country
• Germany

• Manufacturer / Brand
• Heliogen, Hermann Pawlik; Bad Blankenburg (GINOR)

• Year
• 1935 ?

• Category
• Radio module post 1925 (not a part, not a key)

• Radiomuseum.org ID
• 248299

Click on the schematic thumbnail to request the schematic as a free document.

• Main principle
• RF-Circuit or wave trap (separate, can also be an antenna with amp.)

• Wave bands
• Broadcast (MW) and Long Wave.

• Power type and voltage
• No Power needed

• Loudspeaker
• - - No sound reproduction output.

• Material
• Bakelite case

• from Radiomuseum.org
• Model: Sideron-Festsperrkreis 83... - Heliogen, Hermann Pawlik; Bad

• Dimensions (WHD)
• 40 x 47 x 30 mm / 1.6 x 1.9 x 1.2 inch

• Notes

• Sperrkreis mit Feinabgleich, für eine fest eingestellte Wellenlänge (Sendername). Die Modellnummer ist dementsprechend z. B. 83 222 oder 83 375 oder 83 1490.

• Net weight (2.2 lb = 1 kg)
• 0.040 kg / 0 lb 1.4 oz (0.088 lb)

• Price in first year of sale
• 2.00 RM

• Mentioned in
• Heliogen-Katalog RZ 200, 1936

• Author
• Model page created by Wolfgang Eckardt. See "Data change" for further contributors.
