548 Ch= A537DM/RG

Country:  Australia
Manufacturer / Brand:  His Master's Voice (HMV, H.M.V.), EMI (Australia) Ltd.; Sydney, NSW
Year: 1948 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 6J8GA EBF35 6U7G 6V6GT 5Y3GT
Main principle Super-Heterodyne (Super in general); ZF/IF 457.5 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast and Short Wave (SW).
Details Record Player (not changer)
Power type and voltage Alternating Current supply (AC) / 200-220; 221-240; 241-250 Volt
Loudspeaker 2 Loudspeakers
Power out
from Radiomuseum.org Model: 548 Ch= A537DM/RG - His Master's Voice HMV, H.M.V.
Material Wooden case
Shape Console, Lowboy (legs < 50 %).
Dimensions (WHD) 36 x 31 x 18 inch / 914 x 787 x 457 mm
Notes This model has a 6 inch tweeter and a 10 inch woofer.
Circuit diagram reference Australian Official Radio Service Manual Vol. VII

Model page created by Stuart Irwin. See "Data change" for further contributors.
