Consort JG-1P Ch= JG

Consort JG-1P Ch= JG; His Master's Voice (ID = 1330206) Radio Consort JG-1P Ch= JG; His Master's Voice (ID = 2375358) Radio
Consort JG-1P Ch= JG; His Master's Voice (ID = 2375356) Radio Consort JG-1P Ch= JG; His Master's Voice (ID = 1330207) Radio
Consort JG-1P Ch= JG; His Master's Voice (ID = 2375357) Radio Consort JG-1P Ch= JG; His Master's Voice (ID = 2375359) Radio
Use red slider bar for more.
Consort JG-1P Ch= JG; His Master's Voice (ID = 1330206) Radio
His Master's Voice: Consort JG-1P Ch= JG [Radio] ID = 1330206 500x285
Select picture or schematic to display from thumbnails on the right and click for download.
For model Consort JG-1P Ch= JG, His Master's Voice (HMV, H.M.V.), EMI (Australia) Ltd.; Sydney, NSW:
Courtesy of Ian Malcolm (.transistor.bigpondhosting.com)

Country:  Australia
Manufacturer / Brand:  His Master's Voice (HMV, H.M.V.), EMI (Australia) Ltd.; Sydney, NSW
Year: 1966 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 7: OC170 OC170 OC169 OC44 OC75 AC132 AC127
Main principle Super-Heterodyne (Super in general)
Wave bands Broadcast only (MW).
Details
Power type and voltage Dry Batteries / 9 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Consort JG-1P Ch= JG - His Master's Voice HMV, H.M.V.
Material Leather / canvas / plastic - over other material
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 270 x 150 x 90 mm / 10.6 x 5.9 x 3.5 inch
Notes

See also model Consort J8-1C with the model name on the left side.

For further information, refer to the Service Manual for chassis type J8.

Battery: Eveready 276P or similar.

Net weight (2.2 lb = 1 kg) 5 lb 4 oz (5.25 lb) / 2.384 kg
Price in first year of sale 63.80 AUS $
Source of data -- Schematic
