• Year
  • 1965/1966
  • Category
  • Television Receiver (TV) or Monitor
  • Radiomuseum.org ID
  • 298644

 Technical Specifications

  • Number of Tubes
  • 16
  • Number of Transistors
  • 3
  • Main principle
  • Superhet with RF-stage
  • Wave bands
  • VHF incl. FM and/or UHF (see notes for details)
  • Power type and voltage
  • Alternating Current supply (AC) / 230-250 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Savoy PN-AC Ch= PN Series 3 - His Master's Voice HMV, H.M.V.
  • Shape
  • Console with any shape - in general
  • Dimensions (WHD)
  • 29.5 x 32 x 16.5 inch / 749 x 813 x 419 mm
  • Notes
  • Remote control version of model Savoy PL-AC Series 3.

    Series 3 chassis differs to Series 2 by changes of two 6BX6's with two SE1001 transistors.

    Cabinet finishes in Walnut, Maple & Rosewood.

  • Net weight (2.2 lb = 1 kg)
  • 140 lb 0 oz (140 lb) / 63.560 kg
  • Price in first year of sale
  • 480.90 AUS $
  • Literature/Schematics (1)
  • - - Manufacturers Literature (HMV Service Manual for Chassis Types PL & PN Series 3.)
  • Author
  • Model page created by Martin Kent. See "Data change" for further contributors.
